| Drill depth mm | 179.9 |
| Minimum diameter mm | 57.00 |
| Maximum diameter mm | 62.99 |
| Shank diameter mm | 50 |
| Shank length mm | 80 |
| Shank type | Flanged |
| Series | 57 |
| Flute Type | Helical |
| Length Type | 3xØ |
| Assembled overall length mm | 322.7 |
| Assembled reference length mm | 242.7 |
| Coolant Inlet Style Rear | Through the Shank |
